Công cụ cắt PCBN (Dao cắt cho gia công),DCGW

Tải về

Trang web: https://winicetech-vn.com/pcbn-cutting-tools-dcgw-2-2-2.html

Thông số kỹ thuật

Mã ISO	Mã ANSI	Mảnh	Chiều dài cạnh	oChiều dài cạnh	Chiều dài cạnh cắt	Đường kính lỗ	Bán kính mũi dao	Độ dài mảnh dao	H	K	S
				ic	Ød	s	r	la
DCGW070202	DCGW2(1.5)(0.5)	2N	Tiêu chuẩn	6.35	2.8	2.38	0.2	2.2	●	●	●
DCGW070204	DCGW2(1.5)1						0.4
DCGW070208	DCGW2(1.5)2						0.8
DCGW070202	DCGW2(1.5)(0.5)	2N	Lưỡi gạt	6.35	2.8	2.38	0.2	2.2	●	●	●
DCGW070204	DCGW2(1.5)1						0.4
DCGW070208	DCGW2(1.5)2						0.8
DCGW070202	DCGW2(1.5)(0.5)	2N	Bẻ phoi	6.35	2.8	2.38	0.2	2.2	●	●	●
DCGW070204	DCGW2(1.5)1						0.4
DCGW070208	DCGW2(1.5)2						0.8
DCGW070202	DCGW2(1.5)(0.5)	2N	Tiêu chuẩn	6.35	2.8	2.38	0.2	3	●	●	●
DCGW070204	DCGW2(1.5)1						0.4
DCGW070208	DCGW2(1.5)2						0.8
DCGW070202	DCGW2(1.5)(0.5)	2N	Lưỡi gạt	6.35	2.8	2.38	0.2	3	●	●	●
DCGW070204	DCGW2(1.5)1						0.4
DCGW070208	DCGW2(1.5)2						0.8
DCGW070202	DCGW2(1.5)(0.5)	2N	Bẻ phoi	6.35	2.8	2.38	0.2	3	●	●	●
DCGW070204	DCGW2(1.5)1						0.4
DCGW070208	DCGW2(1.5)2						0.8
DCGW11T304	DCGW3(2.5)1	2N	Tiêu chuẩn	9.525	4.4	3.97	0.4	2.2	●	●	●
DCGW11T308	DCGW3(2.5)2						0.8
DCGW11T312	DCGW3(2.5)3						1.2
DCGW11T304	DCGW3(2.5)1	2N	Lưỡi gạt	9.525	4.4	3.97	0.4	2.2	●	●	●
DCGW11T308	DCGW3(2.5)2						0.8
DCGW11T312	DCGW3(2.5)3						1.2
DCGW11T304	DCGW3(2.5)1	2N	Bẻ phoi	9.525	4.4	3.97	0.4	2.2	●	●	●
DCGW11T308	DCGW3(2.5)2						0.8
DCGW11T312	DCGW3(2.5)3						1.2
DCGW11T304	DCGW3(2.5)1	2N	Tiêu chuẩn	9.525	4.4	3.97	0.4	3	●	●	●
DCGW11T308	DCGW3(2.5)2						0.8
DCGW11T312	DCGW3(2.5)3						1.2
DCGW11T304	DCGW3(2.5)1	2N	Lưỡi gạt	9.525	4.4	3.97	0.4	3	●	●	●
DCGW11T308	DCGW3(2.5)2						0.8
DCGW11T312	DCGW3(2.5)3						1.2
DCGW11T304	DCGW3(2.5)1	2N	Bẻ phoi	9.525	4.4	3.97	0.4	3	●	●	●
DCGW11T308	DCGW3(2.5)2						0.8
DCGW11T312	DCGW3(2.5)3						1.2
DCGW150404	DCGW431	2N	Tiêu chuẩn	12.7	5.5	4.76	0.4	2.2	●	●	●
DCGW150408	DCGW432						0.8
DCGW150412	DCGW433						1.2
DCGW150404	DCGW431	2N	Lưỡi gạt	12.7	5.5	4.76	0.4	2.2	●	●	●
DCGW150408	DCGW432						0.8
DCGW150412	DCGW433						1.2
DCGW150404	DCGW431	2N	Bẻ phoi	12.7	5.5	4.76	0.4	2.2	●	●	●
DCGW150408	DCGW432						0.8
DCGW150412	DCGW433						1.2
DCGW150404	DCGW431	2N	Tiêu chuẩn	12.7	5.5	4.76	0.4	3	●	●	●
DCGW150408	DCGW432						0.8
DCGW150412	DCGW433						1.2
DCGW150404	DCGW431	2N	Lưỡi gạt	12.7	5.5	4.76	0.4	3	●	●	●
DCGW150408	DCGW432						0.8
DCGW150412	DCGW433						1.2
DCGW150404	DCGW431	2N	Bẻ phoi	12.7	5.5	4.76	0.4	3	●	●	●
DCGW150408	DCGW432						0.8
DCGW150412	DCGW433						1.2
